High-precision V-type transmission guide + precision polished rod
Han Ding customized 2 million pixel ultra-clear industrial digital camera
Continuously adjustable LED lamp (surface light source + contour light source)
The website only displays some products, more products can be inquired about. Accurately recommend products based on your needs and support customization!
| Model |
HD-212HM |
HD-322HM |
HD-432HM |
| X/Y/Z Measurement Travel |
200╳100╳200mm |
300╳200╳200mm |
400╳300╳200mm |
| Glass Table Load Capacity |
30kg |
||
| Transmission Type | High-precision V-type transmission guide + precision polished rod | ||
| Closed-loop Grating | Three-axis resolution: 0.001mm | ||
| X/Y Linear Measurement Accuracy (μm) |
≤3+L/200 |
||
| X/Y Repeatability (μm) |
≤3 |
||
| Camera | Han Ding customized 2 million pixel ultra-clear industrial digital camera | ||
| Lens |
POMEAS fixed position continuous zoom lens Optical magnification: 0.7X-4.5X Camera maximum magnification: 20X-180X Magnification ratio is approximate, related to the size and resolution of the display |
||
| Light Source System | Continuously adjustable LED lamp (surface light source + contour light source) | ||
| Monitor |
AOC 21" |
||
| Computer Main Unit | intel i3+4G+256G | ||
| Warranty | Entire machine for 12 months | ||
| Power Supply |
AC220V/50HZ AC110V/60HZ |
||
| Instrument Weight |
180kg |
190kg |
230kg |
| Dimensions of table not included(L*W*H) | L522*W548*H734 | L731*W653*H1554 | L772*W881*H1554 |
Enter the data in.......
