As Handing Optics, a direct manufacturer with 15 years of dedication to optical inspection equipment, today we're thrilled to introduce an extraordinary tool to the PCB industry-Splicing instant vision measuring machine. This device is designed to revolutionize PCB dimensional measurement, offering a "no-fixture, free-placement, 3,000-dimension-in-one-test" solution. Its sole mission? To make PCB dimensional measurement incredibly fast and amazingly accurate!

1. Why Is It the "Benchmark" for PCB Dimensional Measurement?

① Unmatched Measurement Range with Customization Options

- Standard Models: Available in 300×200mm, 400×300mm, and 500×400mm sizes, covering over 90% of common PCB board types.

- Customizable Models: Capable of handling an extra-large format of 700mm×800mm. We can customize according to your specific requirements!

② Fixture - Free and Hassle - Free Measurement

Gone are the days of complicated positioning setups! Simply place the PCB board randomly on the testing platform. After automatic image stitching, 3,000 dimensions (including hole diameters, line widths, spacing, and outer shapes) will be measured in an instant.

Customer Case: A certain automotive PCB with 2,800 holes used to take 40-80 minutes per board to measure, but now it only takes 3 minutes!

③ Optional Laser Modules for 3D Data Collection

- Laser Height Measurement: Measure the depth of through-holes, the height of gold fingers, and the protrusion of components, and directly generate 3D models.

- Line-Scan Laser: Analyze contour accuracy, warpage, and curved surface radians, even for complex structures.

2. Scenarios Where Customers Are Full of Praise

* A Lifesaver for Quick Prototyping

Engineer's Feedback: "I revised the drawings at midnight and needed to measure 10 prototype boards in the morning. The flash tester got it done in 20 minutes, faster than ordering takeout!"

* Mass Production Quality Control

Production Supervisor's Comment: "Previously, we relied on manual sampling with an image measuring instrument. Now, every board undergoes automatic measurement of 3,000 points, and defective products have nowhere to hide!"

3. Three Compelling Reasons to Choose Us

✅ Cost - Effective Pricing

Customized models are 60% cheaper than imported equipment!

✅ User - Friendly Operation

Complete the measurement in three simple steps: place the board → take a photo → obtain the report.

✅ Permanent Data Traceability

Automatically generate Excel reports, support QR-code scanning for historical data queries, and easily meet ISO certification requirements.

Why Make PCB Dimensional Measurement Complicated?

* Visit our official website www.vmm2d.com or call 0086 - 13038878595. Let Handing Optics demonstrate with practical results what "one-step dimensional measurement" truly means!
